Preparing your data: from fitted models to F

library(MetaHunt)
set.seed(1)

Why this step matters

Most users arrive at MetaHunt with one fitted model per study (a random forest from each centre, a causal forest from each trial site, a linear model from each cohort), not with the m-by-G numeric matrix F_hat that the rest of the package consumes. The two onramp helpers in MetaHunt — build_grid() and f_hat_from_models() — bridge that gap.

The conceptual picture is simple. Pick a finite set of “patient profiles” (the grid); evaluate every centre’s model at every profile; stack the resulting numeric vectors as rows. The output is F_hat, where F_hat[i, g] is the prediction of centre i’s model at grid point g.

This tutorial walks through that two-step flow and covers:

the dispatch table f_hat_from_models() uses,
a fully-worked dependency-free example with lm,
the predict_fn escape hatch for custom model classes,
a multi-dimensional grid,
the sanity checks worth running before plugging the result into metahunt().

`build_grid()`

build_grid() constructs a data frame of grid points from any reference patient-level dataset. The reference data should have the same columns and live on the same scale as the data each centre’s model was trained on. Common choices, in rough order of preference:

A held-out sample from the target population. Best if you have one — even 50–500 rows is enough. The grid then is a draw from the measure you care about and the default uniform grid_weights is exactly right.
A public dataset of the same population. For clinical work, e.g. NHANES, MEPS, or a national survey. For political-science replications, a public benchmark like the World Values Survey or ANES individual-level files works.
A small individual-level sample from a single source site, if your privacy regime allows one site to share its covariates (but not outcomes). This is common in multi-site clinical trials where one site can provide a covariate sample under a covariate-only DUA.
A synthetic grid based on summary statistics. If no individual-level data are available anywhere, construct a grid by sampling from marginal distributions whose moments you have agreed summary statistics for. This is the most permissive option but the least faithful — distances over the grid will reflect the independence assumption you imposed.

Whatever you pick, the grid must use the same column names and encodings the per-site models were trained with — f_hat_from_models() will call predict(model, newdata = grid) and silently produce nonsense if (say) factor levels disagree.

ref <- data.frame(age = rnorm(500, 60, 10),
                  bp  = rnorm(500, 130, 15),
                  bmi = rnorm(500, 28, 4))
grid <- build_grid(ref, n_grid = 50, seed = 1)
dim(grid)
#> [1] 50  3
head(grid)
#>          age        bp      bmi
#> 324 41.30211 131.21499 22.61675
#> 167 57.44973 109.91799 31.05163
#> 129 53.18340 125.20321 25.30332
#> 418 57.48835 140.33866 32.35510
#> 471 51.86756 136.83815 21.86313
#> 299 59.49434  91.05833 26.37670

If n_grid is NULL (or at least nrow(reference_data)), the full reference data is returned unchanged. Otherwise n_grid rows are sampled uniformly without replacement.

The empirical distribution of the returned grid implicitly defines the measure mu used by the L^2(mu) inner product downstream. If your grid is itself a representative sample of the population you care about, the default uniform grid_weights is appropriate. If the grid was sampled from one population but you want distances to reflect another, pass non-uniform grid_weights proportional to the target density at each grid point. See vignette("grid-weights").

`f_hat_from_models()`

f_hat_from_models(models, grid) takes a list of fitted model objects and the grid you just built, and returns the m-by-G_grid numeric matrix F_hat.

Dispatch table

Internally, f_hat_from_models() dispatches on each model’s class:

Class	Call form
`ranger`	`predict(model, data = grid)$predictions`
`grf::causal_forest`, `regression_forest`	`predict(model, newdata = grid)$predictions`
anything else	`as.numeric(predict(model, newdata = grid))`

The default branch covers lm, glm, randomForest, and most other R model objects whose predict() method returns a numeric vector when called with newdata.

`ranger` example (not run)

library(ranger)
centre_models <- lapply(centre_data_list,
                        function(d) ranger(y ~ ., data = d))
F_hat <- f_hat_from_models(centre_models, grid)

`grf::causal_forest` example (not run)

library(grf)
centre_models <- lapply(centre_data_list,
                        function(d) causal_forest(d$X, d$Y, d$W))
F_hat <- f_hat_from_models(centre_models, grid)

These chunks are eval = FALSE so this vignette does not depend on ranger or grf — installing either is unnecessary just to read the tutorial.

Worked `lm` example

To keep the tutorial fully reproducible without external dependencies, here is a complete onramp using lm() as the per-centre model. (This is the same lm-onramp flow that previously appeared in the introductory vignette, broken out and annotated.)

m <- 8
centre_meta <- data.frame(
  region     = factor(sample(c("N", "S", "E", "W"), m, replace = TRUE)),
  mean_age   = round(runif(m, 50, 70)),
  pct_female = round(runif(m, 0.4, 0.6), 2)
)

# Each centre fits a quadratic on a single covariate `x`.
make_centre_data <- function(i) {
  x <- runif(80, -1, 1)
  beta <- centre_meta$mean_age[i] / 60      # toy effect of metadata
  data.frame(x = x, y = beta * x + 0.3 * x^2 + rnorm(80, sd = 0.2))
}
centre_models <- lapply(seq_len(m), function(i)
  stats::lm(y ~ poly(x, 2), data = make_centre_data(i)))

# A 1-D grid in the centres' covariate space.
grid_centres  <- data.frame(x = seq(-1, 1, length.out = 30))
F_hat_centres <- f_hat_from_models(centre_models, grid_centres)

dim(F_hat_centres)        # 8 x 30
#> [1]  8 30
F_hat_centres[1:3, 1:5]
#>            [,1]       [,2]       [,3]       [,4]       [,5]
#> [1,] -0.6884554 -0.6575489 -0.6241455 -0.5882450 -0.5498475
#> [2,] -0.6822055 -0.6615548 -0.6371818 -0.6090865 -0.5772689
#> [3,] -0.6552212 -0.6306971 -0.6031561 -0.5725983 -0.5390236

You now have F_hat_centres (m × G_grid) and centre_meta (m × p), which are everything metahunt() needs.

`predict_fn` for custom S4 / bespoke classes

If your fitted models are S4 objects, ensembles, or otherwise need custom handling, override the dispatcher with predict_fn. The function must accept (model, grid) and return a length-nrow(grid) numeric vector:

# Toy "model" that is just a list with a slope. predict_fn evaluates it.
fake_models <- lapply(seq_len(4), function(i)
  list(slope = i / 4, intercept = 0))

custom_predict <- function(model, grid) {
  model$intercept + model$slope * grid$x
}

F_hat_custom <- f_hat_from_models(fake_models, grid_centres,
                                  predict_fn = custom_predict)
dim(F_hat_custom)         # 4 x 30
#> [1]  4 30

This same pattern extends to S4 model objects: write a one-line adapter that pulls predictions out and coerces to a numeric vector.

Multi-dimensional grids (3 covariates)

The grid does not need to be one-dimensional. With more than one patient-level covariate, sample the grid from a multivariate reference dataset and let predict() evaluate at each row.

# A 3-covariate reference dataset and a sub-sampled grid.
ref3   <- data.frame(age = rnorm(400, 60, 10),
                     bp  = rnorm(400, 130, 15),
                     bmi = rnorm(400, 28,  4))
grid3  <- build_grid(ref3, n_grid = 25, seed = 1)
dim(grid3)
#> [1] 25  3

# Each centre fits an lm on (age, bp, bmi); slopes vary across centres
# so there is genuine cross-centre heterogeneity to recover.
set.seed(2)
m3 <- 8
centre_data3 <- lapply(seq_len(m3), function(i) {
  n_i <- 60
  age <- rnorm(n_i, 60, 10)
  bp  <- rnorm(n_i, 130, 15)
  bmi <- rnorm(n_i, 28, 4)
  # slopes vary across centres
  beta_age <- 0.02 + 0.03 * (i / m3)
  beta_bp  <- -0.01 + 0.02 * cos(pi * i / m3)
  beta_bmi <- 0.05 - 0.04 * (i / m3)
  y <- beta_age * age + beta_bp * bp + beta_bmi * bmi + rnorm(n_i, sd = 0.3)
  data.frame(age = age, bp = bp, bmi = bmi, y = y)
})
centre_models3 <- lapply(centre_data3, function(d) stats::lm(y ~ age + bp + bmi, data = d))

F_hat3 <- f_hat_from_models(centre_models3, grid3)
dim(F_hat3)               # 8 x 25
#> [1]  8 25

The number of grid points G_grid is yours to choose. Larger grids give finer-resolution function estimates; smaller grids run faster. A few dozen to a few hundred is typical.

Sanity checks

After building F_hat, run these quick checks before passing it into the rest of the pipeline:

# Right shape: m studies x G grid points.
dim(F_hat3)
#> [1]  8 25

# Numeric, no NA.
is.numeric(F_hat3)
#> [1] TRUE
anyNA(F_hat3)
#> [1] FALSE

# Rows look like functions of similar magnitude (large outliers can
# dominate d-fSPA's `Delta`).
summary(apply(F_hat3, 1, function(r) c(min = min(r), max = max(r))))
#>        V1              V2              V3              V4
#>  Min.   :3.081   Min.   :2.642   Min.   :1.807   Min.   :0.6285
#>  1st Qu.:3.429   1st Qu.:2.992   1st Qu.:2.209   1st Qu.:1.2012
#>  Median :3.777   Median :3.341   Median :2.612   Median :1.7738
#>  Mean   :3.777   Mean   :3.341   Mean   :2.612   Mean   :1.7738
#>  3rd Qu.:4.125   3rd Qu.:3.690   3rd Qu.:3.015   3rd Qu.:2.3464
#>  Max.   :4.473   Max.   :4.039   Max.   :3.418   Max.   :2.9190
#>        V5                V6                V7                V8
#>  Min.   :-0.3436   Min.   :-1.1371   Min.   :-1.8484   Min.   :-1.9006
#>  1st Qu.: 0.2655   1st Qu.:-0.4827   1st Qu.:-1.1030   1st Qu.:-1.1305
#>  Median : 0.8745   Median : 0.1718   Median :-0.3576   Median :-0.3605
#>  Mean   : 0.8745   Mean   : 0.1718   Mean   :-0.3576   Mean   :-0.3605
#>  3rd Qu.: 1.4836   3rd Qu.: 0.8262   3rd Qu.: 0.3877   3rd Qu.: 0.4095
#>  Max.   : 2.0926   Max.   : 1.4806   Max.   : 1.1331   Max.   : 1.1796

A quick visual check on a 1-D grid is also worth the cost:

matplot(grid_centres$x, t(F_hat_centres), type = "l", lty = 1,
        col = "grey50",
        xlab = "x", ylab = expression(hat(f)(x)),
        main = "Per-centre fitted functions on the shared grid")

If a single centre’s curve is wildly far from the rest, that often flags a bug (mis-scaled covariate, an lm with the wrong response) rather than a real low-rank-violating outlier.

Common pitfalls

Different columns across centres. Every centre’s model must accept rows of the same grid data frame. If centre A was fit on (age, bp) and centre B was fit on (age, bmi), you cannot share a grid; harmonise the covariates first.
Categorical levels. Factor levels in grid must match those the model saw at training. Pre-build levels explicitly with factor(x, levels = ...) if needed.
Wrong return shape from predict_fn. Must be a length-G_grid numeric vector. f_hat_from_models() errors if the length is wrong or any value is NA.
Using a non-representative grid. The grid implicitly defines the measure mu. A grid concentrated in one corner of covariate space will under-weight other regions. Either resample the grid more evenly, or use non-uniform grid_weights (see vignette("grid-weights")).
Confusing m × p study covariates W with the patient grid. W lives at the study level (one row per centre, columns like region or year). The grid lives at the patient level (one row per profile, columns like age and BMI). They are different objects.
